How to Install a Ceiling Fan

By Rowan Guthrie

June 29, 2018

They say the fan is mightier than the air conditioner at cooling a room. In these energy-conscious times, a ceiling fan can be your best friend — circulating air to create a refreshing breeze while putting substantially less strain on your utility bills than air conditioning.

This May Also Interest You: How Much Does Electricity Cost?

So, if you don't have a ceiling fan installed, it's a home upgrade you should consider. And if you do have one? Models have come a long way in recent years, with new features and airflow capabilities that might make an upgrade worthwhile. Either way, installing a ceiling fan is a relatively easy DIY project. Let’s look at how you can do it — step by step.

Replacing Your Light Fixture With a Ceiling Fan

Before starting, gather the right tools and materials for the job. You’ll need the following:

Screwdriver set
Wire cutters/strippers
Pliers
Ladder
Electrical tape
Wire connectors (provided in most fan kits)
New ceiling fan

Safety First: Turn Off the Power

Safety should always be your priority when working with electricity. Locate the circuit breaker controlling the room where the fan's going and switch it off. Double-check by turning on the light switch — if it doesn't work now, you're good to go.

If There’s an Existing Ceiling Fan

Here’s how to remove an existing fan after disconnecting the power.

Climb your ladder and locate the mounting bracket that attaches the fan to the electrical box in the ceiling. There may be screws or other fasteners holding it in place — remove these.

Carefully disconnect the wires connecting the fan to the electrical box. The black wire is the hot wire, white is the neutral wire, and green or bare copper is the ground wire.

Once all wires are disconnected, you can lower the fan and remove it.

Installing a New Ceiling Fan

Most existing light fixtures are designed for lighter loads. If your new fan is heavier, you might need to install a new, fan-rated electrical box. This process is complex, so you may need a qualified electrician. Here are some signs you might need a new box:

Ceiling joist concerns. The ceiling joist where you plan to hang the fan should be able to support its weight. If you're unsure, consult a professional to assess the joist's strength.

Box depth requirements. Standard light fixture boxes may not be deep enough to accommodate the thicker wiring and housing of a ceiling fan. A fan-rated box ensures sufficient space and secure mounting.

Multiple fans or circuits. If you plan to install several fans or control them with separate switches, you'll likely need a new box with additional wiring capacity. As previously mentioned, unless you’re sure you know what you’re doing — hire a professional.

Installing a Ceiling Fan

Tools at the ready? Power turned off at the circuit breaker? Light fixture removed? Okay, now you're prepared to install the ceiling fan.

Step 1: Inspect and Prep Wiring

Inspect the house wiring in your ceiling electrical box. There should be black (hot), white (neutral) and green or bare copper (ground) wires. Use wire strippers to remove about 3/4 inch (1.9 cm) of sheathing from each wire end if needed.

Step 2: Attach Mounting Bracket

Follow the manufacturer's instructions to install the mounting bracket or plate that came with your new ceiling fan. This attaches to the electrical box and will support the fan.

Step 3: Lift and Hang Fan Motor Housing

Once the bracket is secure, you can lift the fan motor housing and hang it from the hook on the bracket. There should be socket terminals where you can connect your wiring.

More Related Articles:

Step 4: Connect Wiring

Using wire connectors, connect the wiring as follows:

Black fan wire to black house wire (hot)
White fan wire to white house wire (neutral)
Green fan wire to green/bare house wire (ground)

Secure the wire connectors with electrical tape for extra protection. Tuck the connected wires neatly into the ceiling box.

Step 5: Secure Housing and Attach Fan Blades

Follow the manufacturer’s instructions to secure the housing cover and attach the blades or light kits that came with your particular fan model. Most use simple twisting or clipping mechanisms, so you shouldn't need special tools.

Step 6: Turn Power Back On

Double-check that your fan is securely installed, and switch the circuit breaker back to the "on" position. You may need to turn on a wall switch to get the fan to operate.

That's it — you’ve installed your new ceiling fan. Give those new blades a spin and check the airflow.

Additional Tips for a Smooth Installation

Take measurements to ensure the ceiling fan suits the room’s size. If the fan’s too large, it will overpower the space, but if it's too small, it won’t provide adequate airflow. Also, check the ceiling’s height to ensure the fan blades won't obstruct doorways or pose a safety hazard.

Read the manufacturer’s manual carefully as different fan models have varying installation processes. Also, enlist help where it makes sense, such as someone to hold the fan while you secure the mounting plate or connect the wires.

Seek help from a qualified electrician if you encounter challenges. Electrical work can be dangerous, so it's always better to be cautious if you're unsure about any aspect of the installation.
